Unique Features
Powertrain
- 3.5L EcoBoost HO engine.
- 10R80 10-speed automatic transmission.
- Torque On Demand™ 2-speed transfer case with 4 Hi-Loc.
- Modified rear differential capable of locking in 4A, 4H and 4L.
- 35 spline rear axle shafts for increased capability.
- 4.10 front and rear axle ratios.
- Dual exhaust, 4.5 in (114.3 mm) exhaust tips.
Chassis
- Longer, cast aluminum lower control arms.
- Longer, forged steel upper control arms.
- Fox Racing 2.25 in (57.15 mm) piston, 3 in (76.2 mm) body, internal bypass front shocks.
- Fox Racing 2.25 in (57.15 mm) piston, 3 in (76.2 mm) body, internal bypass, remote reservoir rear shocks.
- Long travel suspension.
- Unique underbody shields.
- Heavy duty fully boxed frame.
Exterior
- Modified rear bumper with integrated rear tow hooks.
- Unique underbody shields plus front tow hooks.
- Hood with functional air extractors.
- Front fenders with functional air extractors.
- Front and rear LED marker lamps.
- 17 x 8.5 aluminum wheels.
- Optional 17 x 8.5 forged beadlock compatible wheels.
- LT 315/70-17 BF Goodrich all-terrain tires.
Interior
- Unique terrain-mode and hill descent functionality plus six auxiliary switches.
- Off-road specific calibrations for engine, transmission, driveline and AdvanceTrac system.
