Capacities and Specifications - 2.7L EcoBoost™
If you use oil and fluids that do not meet the defined specification and viscosity grade, this may lead to:
Capacities
WARNING:
The air conditioning refrigerant system contains refrigerant under high pressure. Only qualified personnel should service the air conditioning refrigerant system. Opening the air conditioning refrigerant system can cause personal injury. |
| Item | Capacity |
|---|---|
| Engine oil. | 6.0 qt (5.7 L) |
| Engine coolant. | 12.4 qt (11.7 L) |
| Brake fluid. | Between MIN/MAX on brake fluid reservoir |
| Rear differential fluid. | 28.07 ± 1.01 fl oz (830 ± 30 ml) |
| Power Transfer Unit (PTU) fluid. | 12.7 ± 1.7 fl oz (375 ± 50 ml) |
| Automatic transmission fluid. | 12.15 qt (11.5 L)1 |
| Windshield washer fluid. | Fill as required |
| Fuel tank. | 18.5 gal (70 L) |
| A/C refrigerant (U.S. and Canada). | 21 oz (0.595 kg) |
| A/C refrigerant (Mexico). | 22 oz (0.624 kg) |
| A/C refrigerant compressor oil. | 3.2 fl oz (95 ml) |
1 Approximate dry fill capacity. Actual amount may vary during fluid changes.
Specifications
Materials
| Name | Specification |
|---|---|
| Motor oil (U.S.): Motorcraft® SAE 5W-30 Premium Synthetic Blend Motor Oil XO-5W30-Q1SP | WSS-M2C946-B1 |
| Motor oil (Canada): Motorcraft® SAE 5W-30 Super Premium Motor Oil CXO-5W30-LSP6 | WSS-M2C946-B1 |
| Motor oil (Mexico): Motorcraft® SAE 5W-30 Synthetic Motor Oil MXO-5W30-QSP | WSS-M2C946-B1 |
| Engine coolant (U.S. and Mexico): Motorcraft® Yellow Prediluted Antifreeze/Coolant VC-13DL-G | WSS-M97B57-A2 |
| Engine coolant (Canada): Motorcraft® Yellow Prediluted Antifreeze/Coolant CVC-13DL-G | WSS-M97B57-A2 |
| Brake fluid: Motorcraft® DOT 4 Low Viscosity (LV) High Performance Motor Vehicle Brake Fluid PM-20 | WSS-M6C65-A2 |
| Rear differential (All-wheel drive) fluid: Motorcraft® SAE 75W Disconnect RDU Fluid XY-75W-QL | - |
| Power Transfer Unit (PTU) fluid (All Wheel Drive): Motorcraft® SAE 75W-85 Premium Synthetic Rear Axle Fluid XY-75W85-QL | WSS-M2C942-A |
| Automatic transmission fluid: Motorcraft® MERCON® ULV Automatic Transmission Fluid XT-12-QULV | WSS-M2C949-A MERCON® ULV |
| Windshield washer fluid (U.S. and Mexico): Motorcraft® Premium Windshield Wash Concentrate with Bitterant ZC-32-B2 | WSS-M14P19-A |
| Windshield washer fluid (Canada): Motorcraft® Premium Quality Windshield Washer Fluid CXC-37-(A, B, D, F) | WSS-M14P19-A |
| A/C refrigerant (U.S.): R-1234yf Refrigerant YN-33-A | WSS-M17B21-A |
| A/C refrigerant (Canada): R-1234yf Refrigerant HS7Z-19B519-BA | WSS-M17B21-A |
| A/C refrigerant (Mexico): Motorcraft® R-134a Refrigerant MYN-19 | WSH-M17B19-A |
| A/C refrigerant compressor oil (U.S. and Canada): Motorcraft® R-1234yf Refrigerant PAG Oil YN-35 | WSS-M2C300-A2 |
| A/C refrigerant compressor oil (Mexico): Motorcraft® PAG Refrigerant Compressor Oil YN-12-D | WSH-M1C231-B |
| Multi-purpose grease: Motorcraft® Multi-Purpose Grease Spray XL-5-A | ESB-M1C93-B |
| Lock cylinders (U.S.): Penetrating and Lock Lubricant XL-1 | - |
| Lock cylinders (Canada): Penetrating Fluid CXC-51-A | - |
| Lock cylinders (Mexico): Penetrating and Lock Lubricant MXL-1 | - |
If you use oil and fluids that do not meet the defined specification and viscosity grade, this may lead to:
- Component damage, which the vehicle warranty does not cover.
- Longer engine cranking periods.
- Increased emission levels.
- Reduced engine performance.
- Reduced fuel economy.
- Reduced brake performance.
We recommend Motorcraft® motor oil for your vehicle.If Motorcraft® oil is not available, use motor oils of the recommended viscosity grade that meet API SN requirements and display the API Certification Mark for gasoline engines. Do not use oil labeled with API SN service category unless the label also displays the API certification mark.
An oil that displays this symbol conforms to current engine, emission system and fuel economy performance standards of ILSAC.
Do not use supplemental engine oil additives because they are unnecessary and could lead to engine damage that may not be covered by your vehicle warranty.
Note:
We recommend using DOT 4 Low Viscosity (LV) High Performance Brake Fluid or equivalent meeting WSS-M6C65-A2. Use of any fluid other than the recommended fluid may cause degraded brake performance and not meet our performance standards. Keep brake fluid clean and dry. Contamination with dirt, water, petroleum products or other materials may result in brake system damage and possible failure.
Note:
Automatic transmissions that require MERCON ULV transmission fluid should only use MERCON ULV transmission fluid.The use of any other fluid may cause transmission damage.
Alternative Engine Oil for Extremely Cold Climates
To improve engine cold start performance, we recommend that you use the following alternative engine oil in extremely cold climates, where the ambient temperature reaches
-22.0 °F (-30 °C) or below.
Materials
| Name | Specification |
|---|---|
| Engine Oil - SAE 0W-30 | WSS-M2C953-B1 |
