General Information
This icon gives you the ability to switch a feature on or off. A check in the box indicates the feature is enabled, and unchecked indicates the feature is disabled.
WARNING:
Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle. We recommend against the use of any hand-held device while driving and encourage the use of voice-operated systems when possible. Make sure you are aware of all applicable local laws that may affect the use of electronic devices while driving. |
Note:
Your vehicle may or may not be equipped with all the messages listed in this chapter. Your vehicle will not display messages of systems it is not equipped with.
Various systems on your vehicle can be controlled using the information display controls on the steering wheel. Corresponding information is displayed in the information display.
Information Display Controls (Type 1)
- Press the up and down arrow buttons to scroll through and highlight the options within a menu.
- Press the right arrow button to enter a sub-menu.
- Press the left arrow button to exit a menu.
- Press and hold the left arrow button at any time to return to the main menu display (escape button).
- Press the OK button to choose and confirm settings or messages.
Menu
You can access the menu using the information display control.
This icon gives you the ability to switch a feature on or off. A check in the box indicates the feature is enabled, and unchecked indicates the feature is disabled.Note:
Some options may appear slightly different or not at all if the items are optional.
| Trip 1 and 2 | ||
|---|---|---|
| Digital Speedo | ||
Distance to E | ||
Trip Odometer | ||
Trip Timer | ||
Average Fuel | ||
Outside Temp. | ||
| All Values |
- Digital Speedo - Shows a digital display of your vehicle speed.
- Distance to E - Shows the approximate distance your vehicle can travel before running out of fuel.
- Trip Odometer — Registers the distance of individual journeys.
- Trip Timer — The timer stops when you turn your vehicle off and restarts when you restart your vehicle.
- Average Fuel — Shows the average fuel economy for a given trip.
- Outside Temperature — Shows the outside air temperature.
- All Values — Shows the Distance to E, Trip Odometer, Trip Timer and Average Fuel.
Note:
Press and hold OK on the current screen to reset the respective trip, distance, time and fuel information.
Fuel Economy |
|---|
Distance to E |
Inst Fuel Econ |
| Avg MPG |
| Long Term Fuel Economy |
Fuel History |
Average Speed |
| All Values |
Auto StartStop |
- Distance to Empty - Shows the approximate distance your vehicle can travel before running out of fuel.
- Inst Fuel Economy - Shows a visual graph of your instantaneous fuel economy along with your Avg MPG since the function was last reset.
- Long Term Fuel Economy - Shows your long term fuel economy.
- Average MPG — Shows the average fuel economy for a given trip.
- Fuel History - Shows the fuel economy over the past 30 minutes.
- Average Speed - Shows the average speed since the last reset.
- All Values — Shows all fuel economy values: Distance to E, Inst Fuel Econ, Long Term Fuel Economy and Average Speed.
- Auto StartStop - Available Auto Start-Stop messaging provides details about what is happening with your system. OK See Information Messages.
Note:
You can reset your average fuel economy by pressing and holding the button on the left-hand steering wheel controls.
Driver Assist | |||
|---|---|---|---|
Blindspot | |||
Cross Traffic | |||
Cruise Control | Select setting | ||
Driver Alert | |||
Hill Start Assist | |||
Intelligent AWD | |||
Lane Keeping | Mode | Select setting | |
Intensity | |||
Pre-Collision | Alert Sensitivity | ||
Dist. Indication | |||
| Evasive Steering Assist | |||
Active Braking | |||
Rear Park Aid | |||
Tire Monitor | Tire Pressure | ||
Hold OK to Reset | |||
Trailer Sway | |||
Settings | ||||||
|---|---|---|---|---|---|---|
Vehicle | Alarm | Select setting | ||||
Ask on exit | ||||||
Auto Engine Off | ||||||
Chimes | Information | |||||
DTE calculation | Select setting | |||||
Easy Entry/Exit | ||||||
Lighting | Auto Highbeam | |||||
Autolamp delay | Select setting | |||||
Daytime Lights | ||||||
Locks | Autounlock | |||||
Mislock | ||||||
Remote Unlock | Select setting | |||||
Switches inhibit | ||||||
Oil Life Reset | Hold OK to Reset | |||||
Power Liftgate | Select setting | |||||
Remote Start | Climate Control | Select setting | ||||
| Seats or Seats and Wheel | ||||||
Duration | ||||||
System | ||||||
Seatbelts | ||||||
Silent mode | ||||||
Windows | Remote Open | |||||
Remote Close | ||||||
Wipers | Courtesy Wipe | |||||
Rain Sensing | ||||||
Reverse Wiper | ||||||
MyKey | Create MyKey | Hold OK to Create MyKey | ||||
911 Assist | Select setting | |||||
| Emergency Assist | ||||||
Do Not Disturb | ||||||
Traction Ctrl | ||||||
Max Speed | ||||||
Speed Minder | ||||||
Volume Limiter | ||||||
Clear MyKeys | Hold OK to Clear All MyKeys | |||||
Display | Units | Select setting | ||||
Distance | ||||||
Temperature | ||||||
Tire Pressure | ||||||
Language | ||||||
Information Display Controls (Type 2)
- Press the up and down arrow buttons to scroll through and highlight the options within a menu.
- Press the right arrow button to enter a sub-menu.
- Press the left arrow button to exit a menu.
- Press and hold the left arrow button at any time to return to the main menu display (escape button).
- Press the OK button to choose and confirm settings or messages.
Main menu
From the main menu bar on the left side of the information display, you can choose from the following categories:
- Display Mode
- Trip 1 & 2
- Fuel Economy
- Driver Assist
- Settings
Scroll up or down to highlight one of the categories, then press the right arrow key or OK to enter into that category. Press the left arrow key as needed to exit back to the main menu.
Display Mode
Use the up/down arrow buttons to choose between the following display options.
Display Mode | Option 1 | Option 2 | Option 3 | Option 4 | ||
|---|---|---|---|---|---|---|
| XXX mi (km) to empty | X | X | - | - | ||
| Round tachometer | - | - | X | X | ||
| Vertical tachometer | - | X | - | - | ||
| Tire Pressure on demand screen | ||||||
| Digital Speedometer - XXX MPH - Press OK for km/h | ||||||
Intelligent AWD | ||||||
| Turbo Boost Gauge1 | ||||||
1ST only.
- XXX mi (km) to empty: Shows the approximate distance the vehicle will travel.
- Round tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine. During SelectShift Automatic™ transmission (SST) use, the currently selected gear will appear in the display.
Trip 1 & 2
You can access the menu using the information display control.
Note:
Some options may appear slightly different or not at all if the items are optional.
Trip 1 & 2 | ||
|---|---|---|
| All Values |
All Values — shows all trip values (Trip Timer, Odometer and Average Fuel).
- Trip Odometer — Shows your accumulated trip distance.
- Average Fuel — Shows your average fuel economy for a given trip.
- Trip Timer— The timer stops when you turn your vehicle off and restarts when you restart your vehicle.
Note:
You can reset your trip information by pressing and holding the OK button on the left hand steering wheel controls.
Fuel Economy
Use the left and right arrow buttons to choose the desired fuel economy display.
Fuel Economy |
|---|
| Instant Fuel Economy - Hold OK to Reset |
Auto StartStop |
Fuel History |
Average Speed |
- Inst Fuel Economy - shows a visual graph of your instantaneous fuel economy, average fuel economy and distance to empty.
- Auto StartStop - available Auto Start-Stop messaging will provide details about what is happening with your system. See Information Messages.
- Fuel History - Shows the fuel economy over the past 30 minutes.
- Average Speed - Shows the average speed since the last reset.
Note:
You can reset your average fuel economy by pressing and holding the OK button on the left hand steering wheel controls.
Driver Assist
In this mode, you can configure different driver setting choices.
Note:
Some items are optional and may not appear.
Driver Assist | |||
|---|---|---|---|
Traction Control | |||
Blindspot | |||
Cross Traffic Alert | |||
Cruise Control | Select setting | ||
Driver Alert | |||
Driver Sel. Susp. | |||
Hill Start Assist | |||
Lane Keeping Sys | Mode | Select setting | |
Intensity | |||
Pre-Collision | Alert Sensitivity | ||
Active Braking | |||
Rear Park Aid | |||
Tire Monitor | Hold OK to Reset | ||
Trailer Sway | |||
Settings
In this mode, you can configure different driver setting choices.
Note:
Some items are optional and may not appear.
Settings | ||||||
|---|---|---|---|---|---|---|
Vehicle | Alarm | Select setting | ||||
Ask on Exit | ||||||
Auto Engine Off | ||||||
DTE Calculation | Select setting | |||||
Easy Entry/Exit | ||||||
Lighting | Adaptive Headlamps | Adaptive Headlamps | ||||
Traffic Set Up | Select setting | |||||
Auto Highbeam | ||||||
Autolamp Delay | Select setting | |||||
Daytime Lights | ||||||
Locks | Autolock | |||||
Autounlock | ||||||
Mislock | ||||||
Remote Unlock | Select setting | |||||
Switch Inhibit | ||||||
Mirrors | Autofold | |||||
Oil Life Reset | XXX% - Hold OK to Reset | |||||
Power Liftgate | Select setting | |||||
Remote Start | Climate Control | Select setting | ||||
| Seats or Seats and Wheel | ||||||
Duration | ||||||
System | ||||||
Seatbelts | ||||||
Silent Mode | ||||||
Windows | Remote Open | |||||
Remote Close | ||||||
Wipers | Courtesy Wipe | |||||
Rain Sensing | ||||||
MyKey | Create MyKey | Hold OK to Create MyKey | ||||
911 Assist | Select setting | |||||
| Emergency Assist | ||||||
Do Not Disturb | ||||||
Traction Ctrl | ||||||
Max Speed | ||||||
Speed Minder | ||||||
Volume Limiter | ||||||
Clear MyKeys | Hold OK to Clear All MyKeys | |||||
Display Setup | Distance | Select setting | ||||
Temperature | ||||||
Gauge Display | ||||||
Tire Pressure | ||||||
Language | ||||||
