GENERAL MAINTENANCE INFORMATION
Why Maintain Your Vehicle?
Carefully following the maintenance schedule helps protect against major repair expenses resulting from neglect or inadequate maintenance and may help to increase the value of your vehicle when you sell or trade it. Keep all receipts for completed maintenance with your vehicle.
It is important that you have your vehicle serviced at the proper times. These intervals serve two purposes: first is to maintain the reliability of your vehicle and the second is to keep the cost of owning your vehicle down. It is your responsibility to have all scheduled maintenance performed and to make sure that the materials used meet the specifications identified in this owner's manual. See
Engine Oil Capacity and Specification.
Failure to perform scheduled maintenance and regularly inspect your vehicle may result in vehicle damage not covered by the vehicle Warranty.
Why Maintain Your Vehicle at Your Dealership?
Protecting Your Investment
Maintenance is an investment that pays dividends in the form of improved reliability, durability and resale value. To maintain the proper performance of your vehicle and its emission control systems, make sure you have scheduled maintenance performed at the designated intervals.
Your vehicle comes with the Intelligent Oil-Life Monitor system, a message appears in the instrument cluster display at the proper oil change interval. This interval may be up to one year or 16,000 km, whichever occurs first. When the “oil change required” message appears in the instrument cluster display, it is time for an oil change and to perform the other items shown in the Owner´s Manual. Make sure you perform the oil change within two weeks or 1000 km of receiving the oil change required message . Make sure to reset the Intelligent Oil-Life Monitor after each oil change. See
Resetting the Intelligent Oil Life Monitor.
If your instrument cluster display resets prematurely or becomes inoperative, perform the oil change interval at six months or 8,000 km from your last oil change. Never exceed one year or 16,000 km, whichever occurs first, between oil change intervals.
You can drive high performance vehicles in such a way that may lead to higher oil consumption including extended time at high engine speeds, high loads, engine braking, hard cornering maneuvers, track and off-road usage. Under these conditions, oil consumption can be increased. Check the engine oil level at every refueling and adjust to maintain proper levels to avoid engine damage.
Additives and Chemicals
We do not recommend using chemicals or additives not approved by us as part of your vehicle’s normal maintenance. Please consult your warranty information.
Oils, Fluids and Flushing
In many cases, fluid discoloration is a normal operating characteristic and, by itself, does not necessarily indicate a concern or that the fluid needs to be changed. Have discolored fluids that also show signs of overheating or foreign material contamination, immediately checked.
Make sure to change the vehicle’s oils and fluids at the specified intervals or in conjunction with a repair. Flushing is a viable way to change fluid for many vehicles sub-systems during scheduled maintenance. It is critical that systems are flushed only with new fluid that is the same as that required to fill and operate the system or using our approved flushing chemical.
NORMAL SCHEDULED MAINTENANCE
Intelligent Oil Life Monitor
Your vehicle has an Intelligent Oil Life Monitor that determines when you should change the engine oil based on how your vehicle is used. By using several important factors in calculations, the monitor helps reduce the cost of owning your vehicle and reduces environmental waste at the same time.
Your vehicle lets you know when an oil change is due by displaying a message in the instrument cluster display. The following table provides examples of vehicle use and its impact on oil change intervals. It is a guideline only. Actual oil change intervals depend on several factors and generally decrease with severity of use.
| When to Expect the OIL CHANGE REQUIRED Message
|
|---|
| Interval1
| Vehicle Use and Example
|
|---|
| 7,500–10,000 mi (12,000–16,000 km)
| Normal
|
| Normal commuting with highway driving.
No, or moderate, load or towing.
Flat to moderately hilly roads.
No extended idling.
|
| 5,000–7,500 mi (8,000–12,000 km)
| Severe
|
| Moderate to heavy load or towing.
Mountainous or off-road conditions.
Extended idling.
Extended hot or cold operation.
|
| 3,000–5,000 mi (5,000–8,000 km)
| Extreme
|
| Maximum load or towing.
Extreme hot or cold operation.
|
1Do not exceed the 1 year max oil change interval. Remaining oil life can be accessed through the instrument cluster display.
Scheduled Maintenance services are divided in two categories based on usage: Normal and Severe. Your vehicle must follow the scheduled maintenance plan for normal usage, when it will be made, replacements, inspections, lubrications and adjustments to several items.
Vehicles which are driven under severe or unusual conditions should follow, additionally to the maintenance plan for normal usage, the maintenance plan for severe usage.
The maintenance plan for severe usage is based on road conditions and driving condition and has reduced period or additional services for some items.
Make sure you follow the severe plan indicated for your vehicle if it is used under one or more of the follow conditions:
| A – Road Condition
|
|---|
| A1 – Driving in off-road condition such as irregular, muddy or sandy roads.
|
| A2 – Driving in dirty/gravel condition.
|
| A3 – Driving into flooded area with partial immersion of vehicle (mud or water).
|
| B – Driving Condition
|
|---|
| B1 – Towing a heavy trailer, caravan or carrying heavy loads or when high roof rack loads are carried.
|
| B2 – Driving in stop/go traffic with extended periods of idling.
|
| B3 – Driving in high speeds at long routes.
|
Note:
The maintenance and Lubrication Chart is an essential item for the correct and safe operation of your vehicle and to obtain the best performance and durability.The items described in the chart define specific operations, as well as the replacement of certain parts based on mileage or time of use, whichever occurs first.The operations must be carried out as per the items described in each service.The service technician will notify you of any parts not listed in this chart that need to be replaced or repaired.
Regular maintenance intervals for your vehicle have been established based on rigorous testing.It is important that you have your vehicle serviced at the proper times.These intervals serve two purposes; one is to maintain the reliability of your vehicle and the second is keep your cost of owning the vehicle down.
It is your responsibility to see that all scheduled maintenance is performed and that the materials used meet the specifications identified in this Owner's Manual.
Services must be carried out in accordance with the periods or mileages indicated, whichever occurs first.
Note:
The list of Ford Dealers is available on local Ford website: www.ford.com.br
| General body inspection
|
|---|
| At Every Oil Change Interval as Indicated by the Instrument Cluster Display
| Check the condition of the paintwork, rust points, door trim, wiper blades, replace if necessary, hood lock and child locks, door stops. Lubricate as necessary.
|
| Vehicle interior – Check the Following Items are Working Correctly
|
|---|
| At Every Oil Change Interval as Indicated by the Instrument Cluster Display
| Instrument panel switches, A/C, heater if equipped, lights, headlights, full beam, license plate light, fog light, horn, hazard lights.
|
| Glove box lock and light if equipped, courtesy lights, 12V power outlet, if equipped.
|
| Sunshade, seatbelt lock, including return if equipped.
|
| Wash and wipe stalk for windshield.
|
| Internal and external rear view mirrors, door glass, door locks. Important: carry out the operations using the remote control, if equipped.
|
| Parking brake. Adjust if necessary.
|
| Check the pollen filter and replace it if necessary.
|
| Under the Engine Hood Vehicle on the Ground – Check and Top up if Necessary
|
|---|
| At Every Oil Change Interval as Indicated by the Instrument Cluster Display
| Windshield washer reservoir.
|
| Coolant reservoir.
|
| Brake and or clutch fluid.
|
| Check the fixing of battery cables and cooling system clamps.
|
| Check ducts and sealing from the intake system.
|
| Check accessory drive belts.
|
| Check for signs of leaks, oils, fluids, fuel and water.
|
| Check the TMAP sensor and the EGR valve. Perform cleaning if necessary.
|
| Under the Vehicle With the Vehicle Raised – Visual Inspection
|
|---|
| At Every Oil Change Interval as Indicated by the Instrument Cluster Display
| Irregular tire wear.
|
| Leaks from the engine, transmission, half shafts, front and rear shocks, brake lines and flexible hoses, steering joints, suspension struts, exhaust system baffles, parking brake cable and leaks from the rear axle vent hose.
|
| Manual Operations
|
|---|
| At Every Oil Change Interval as Indicated by the Instrument Cluster Display2
| Drain the engine oil.
Replace the engine oil filter.
Remove tires and wheels to check the condition and brake system leaks. Replace if necessary.
Check the nuts torque from the rear Leaf Spring.
Check the front and rear axle fluid.
Rotate the tires.
Calibrate tires, including spare.
|
| Road Test - Check
|
|---|
| At Every Oil Change Interval as Indicated by the Instrument Cluster Display
| Positioning and or alignment of steering wheel, gear shifting, service brake, indicator light stalk return, internal, external noises.
|
| Brake Fluid Maintenance
|
|---|
| Every 3 Years
| Replace the brake fluid.3
|
3Replace the brake fluid every 3 years with no kilometer’s restriction.
| Other Maintenance Items4
|
|---|
| Every
20,000 mi (32,000 km).
| Replace the pollen filter, more frequently in very dusty conditions.
|
| Every
30,000 mi (48,000 km).
| Replace the air filter - more frequently in very dusty conditions.
|
| Every
40,000 mi (64,000 km).
| Replace the spark plugs.
|
| Every
149,000 mi (240,000 km).
| Replace the rear axle fluid.
Replace the front axle fluid.
Replace the transfer case fluid.
Replace the Automatic Transmission fluid.
|
| Every
149,000 mi (240,000 km).
| Replace accessory drive belts, tensioner and auxiliary pulley.
|
| At
199,000 mi (320,000 km) then every
99,000 mi (160,000 km) or 5 years.
| Replace the coolant.
|
4Ford recommends performing these maintenance items within 5,000 km before the designated distance interval for each item in the table. Do not exceed the designated maximum distance for the interval for each item of the table.
Scheduled Services for Severe Usage
| A1 – Driving in off-road condition such as irregular, muddy or sandy roads
|
|---|
| At Every Oil Change Interval as Indicated by the Instrument Cluster Display
| Replace engine oil and filter.
Inspect engine air filter.
Inspect the spark plugs.
Inspect brake disc and pad.
Inspect suspension and suspension screws and nuts.
|
| Every
30,000 mi (48,000 km).
| Replace Automatic Transmission Fluid.
|
| A2 – Driving in dirty/gravel condition
|
|---|
| At Every Oil Change Interval as Indicated by the Instrument Cluster Display
| Replace engine oil and filter.
Inspect engine air filter.
Inspect the spark plugs.
Inspect air conditioner filter.
Inspect brake disc and pad.
Inspect suspension system.
Inspect steering system.
Inspect hoses and wires.
Inspect air extractor.
|
| A3 – Driving into flooded area with partial immersion of vehicle (mud or water)
|
|---|
| At Every Oil Change Interval as Indicated by the Instrument Cluster Display
| Replace engine oil and filter.
Inspect the spark plugs.
Inspect rear axle fluid.
|
| B1 – Towing a heavy trailer, caravan or carrying heavy loads or when high roof rack loads are carried
|
|---|
| At Every Oil Change Interval as Indicated by the Instrument Cluster Display
| Replace engine oil and filter.
Inspect the spark plugs.
Inspect brake disc and pad.
Inspect suspension and suspension screws and nuts.
Inspect cardan shaft.
Inspect rear axle fluid.
|
| Every
30,000 mi (48,000 km).
| Replace Automatic Transmission Fluid.
|
| B2 – Driving in stop/go traffic with extended periods of idling
|
|---|
| At Every Oil Change Interval as Indicated by the Instrument Cluster Display
| Replace engine oil and filter.
Inspect the spark plugs.
Inspect brake disc and pad.
|
| Every
30,000 mi (48,000 km).
| Replace Automatic Transmission Fluid.
|
| B3 – Driving in high speeds at long routes
|
|---|
| At Every Oil Change Interval as Indicated by the Instrument Cluster Display
| Replace engine oil and filter.
Inspect the spark plugs.
Inspect brake disc and pad.
|
| Every
30,000 mi (48,000 km).
| Replace Automatic Transmission Fluid.
|
Motorcraft® Fast Box

Motorcraft® Fast Box is a work cell exclusively intended to provide basic and routine maintenance services for your vehicle, which can be performed within 2 hours.
Its main objective is to provide agility and transparency, as you can watch the service alongside the mechanic, and enjoying quite competitive prices. Plus, you can safely rely on Ford original parts, and on services performed by trained technicians.
The following is a list of the services offered at the Motorcraft Fast Box:
- Scheduled maintenance checks.
- Change of engine oil, oil filter, spark plugs, brake pads or disks, suspension items, springs and shock absorbers, battery, lamps, wiper blades, cleaners.
- Wheel alignment and balancing.
- Tire services.
- Ford promotional items.
Check for the availability of a Fast Box Motorcraft at your preferred Ford Dealer, or contact Ford Service Desk for a list of the participating Dealers.
SCHEDULED MAINTENANCE RECORD
Your scheduled maintenance record is available at the FordPass app.
Note:
To download the FordPass app, visit your device's app store.
