WARNING:  Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle. We recommend against the use of any hand-held device while driving and encourage the use of voice-operated systems when possible. Make sure you are aware of all applicable local laws that may affect the use of electronic devices while driving.

APhone BNavigation (or Information if your vehicle is not equipped with Navigation) CClimate DSettings EHome FInformation GEntertainment

Press to select any of the following:

• Phone
• Quick Dial
• Phonebook
• History
• Messaging
• Settings

Press to select any of the following:

• My Home
• Favorites
• Previous Destinations
• Point of Interest
• Emergency
• Street Address
• Intersection
• City Center
• Map
• Edit Route Cancel Route

Press to select any of the following:

• Driver Settings
• Recirculated Air
• Auto
• Dual
• Passenger Settings
• A/C
• Defrost

Press to select any of the following:

• Clock
• Display
• Sound
• Vehicle
• Settings
• Help

HOME Press to access your home screen. Depending on your vehicle’s option package and software, your screens may vary in appearance from the descriptions in this section. Your features may also be limited depending on your market. Check with an authorized dealer for availability.

INFORMATION

Press to select any of the following:

• Services
• Travel Link
• Alerts
• Calendar
• Apps

Press to select any of the following:

• AM
• FM
• SIRIUS
• CD
• USB
• BT Stereo
• SD Card
• A/V In

To turn a feature on and off, just touch the graphic with your finger. To get the best performance from the touch-sensitive controls:

• Do not press hard on the controls. They are sensitive to light touch.
• Use your bare finger to touch the center of a touch-control graphic. Touching off-center of the graphic may affect operation of a nearby control.
• Make sure your hands are clean and dry.
• Since the touchscreen operates based on the touch of a finger, you may have trouble using it if you are wearing gloves.
• Keep metal and other conductive material away from the surface of the touchscreen as this may cause electronic interference (for example, inadvertently turning on a feature other than the one you meant to turn on).

Depending on your vehicle and option package, you may also have these controls on your bezel:

• Power: Switch the media or climate features off and on.
• VOL: Control the volume of playing media.
• Fan: Control the speed of the climate system fan.
• Seek and Tune buttons: Use as you normally would in media modes.
• Eject: Eject a CD from the entertainment system.
• SOURCE: Touch the word repeatedly to see all available media modes. The screen does not change, but you see the media change in the lower left status bar.
• SOUND: Touch the word to access the Sound menu where you can adjust settings such as: Bass, Treble, Midrange, Balance and Fade, DSP (Digital Signal Processing), Occupancy Mode and Speed Compensated Volume. (Your vehicle may not have all of these sound options.)
• Hazard flasher: Switch the hazard flashers off and on.

WARNING:  Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle. We recommend against the use of any hand-held device while driving and encourage the use of voice-operated systems when possible. Make sure you are aware of all applicable local laws that may affect the use of electronic devices while driving.

• Do not attempt to service or repair the system. See an authorized dealer.
• Do not operate playing devices if the power cords or cables are broken, split or damaged. Place cords and cables out of the way, so they do not interfere with the operation of pedals, seats, compartments or safe driving abilities.
• Do not leave playing devices in your vehicle during extreme conditions as it could cause them damage. See your device's user guide for further information.
• For your safety, some SYNC functions are speed-dependent. Their use is limited to when your vehicle is traveling at speeds under 3 mph (5 km/h).

Some features of this system may be too difficult to use while your vehicle is moving so they are restricted from use unless your vehicle is stationary.

• Screens crowded with information, such as Point of Interest reviews and ratings, SIRIUS Travel Link sports scores, movie times or ski conditions.
• Any action that requires you to use a keyboard is restricted, such as entering a navigation destination or editing information.
• All lists are limited so the user can view fewer entries (such as phone contacts or recent phone call entries).

To access the available voice commands for the current session, do one of the following:

• During a voice session, press the Help icon (?) in the lower left status bar of the screen.
• Say, "What can I say?" for an on-screen listing of the possible voice commands associated with your current voice session.
• Press the voice icon. After the tone, say, "Help" to hear a list of possible voice commands.

• Make sure the interior of your vehicle is as quiet as possible. Wind noise from open windows and road vibrations may prevent the system from correctly recognizing spoken commands.
• After pressing the voice icon, wait until after the tone sounds and Listening appears before saying a command. Any command spoken prior to this does not register with the system.
• Speak naturally, without long pauses between words.
• At any time, you can interrupt the system while it is speaking by pressing the voice icon.

• If you use the touchscreen, press the Settings icon > Help > Voice Command List.
• If you use the steering wheel control, press the voice icon. After the tone, speak your command clearly.

• Interaction Mode: Novice mode provides detailed interaction and guidance while the advanced mode has less audible interaction and more tone prompts.
• Confirmation Prompts: The system uses these short questions to confirm your voice request. If turned off, the system simply makes a best guess as to what you requested. The system may still occasionally ask you to confirm settings.
• Phone and Media Candidate Lists: Candidate lists are lists of possible results from your voice commands. The system creates these lists when it has the same confidence level of several options based on your voice command.

1. Press the Settings icon > Settings > Voice Control.

1. Select from:

• Interaction Mode
• Confirmation Prompts
• Media Candidate Lists
• Phone Candidate Lists
• Voice Control Volume.

1. Press the voice icon. Wait for the prompt "Please say a command". Another tone sounds to let you know the system is listening.

1. Say any of the following commands:

For example, you can choose from the following on the Navigation home screen:

• My Home
• Favorites
• Previous Destinations
• Point of Interest (POI)
• Emergency
• Street Address
• Intersection
• Cancel Route.

If you choose Street Address from the navigation screen, you can choose from the following:

• Number
• City
• Street Name
• State/Prov.

If you choose Points of Interest from the navigation screen, you can choose from the following:

• Search Area
• Search By Name
• Fuel Station
• ATM
• All Restaurants
• Accommodations
• Parking.

If you choose Intersection from the navigation screen, you can choose from the following:

• 1st Street
• 2nd Street
• City
• State/Prov.
